● 4G LTE-Advanced Cat.18, Max 1.2 Gbps Download
● Faster 4G with 4×4 MIMO and DL 5CA Technologies
● Super-Fast AX1800 Wi-Fi 6
● Dual SIM Failover
● WAN Failover
● 4× Gigabit Ports
● 4× Detachable Cellular Antennas
● 2× Fixed WiFi Antennas
Specifications
ModelAX1800 Wi-Fi 6 4G Cat18 RouterData SpeedWi-Fi 2.4GHz (802.11ax/n/g/b, MIMO 574Mbps)5GHz (802.11ax/ac/an/a, MIMO 1201Mbps)LTELTE FDD: Max 1.2Gbps (DL)/150Mbps (UL)LTE TDD: Max 545Mbps (DL)/90.6Mbps (UL)DC-HSPA+42Mbps (DL)/11.5 Mbps (UL)WCDMAWCDMA: Max 384Kbps (DL)/Max 384Kbps (UL)HardwareDRAM: 256MB (2Gbit) DDR3Flash: 16MB (128Mbit)4 x GbE RJ45: 1 GbE WAN/LAN + 3 GbE LAN2 x SIM Slots (Nano)1 x WPS Button1 x Reset Button
2 x Fixed WiFi Antennas
4 x Detachable Cellular AntennasLED indicators (Power, WiFi, Internet, Signal)SoftwareDHCP: Server, Client List, Address ReservationNAT: Port Forwarding, Port Triggering, UPnP, DMZFirewall: Mac Filter, IP Filter, Domain FilterDDNS: Compatible with 15 more DDNS providersVPN: PPTP/L2TP/OpenVPN/WireGuard/IPsec/ZerotierDNS over TLS: Cloudflare/GoogleSchedule: Schedule Reboot /Wi-Fi ScheduleInternet Protocol version 4 or 6 (IPv4/IPv6)Quality of Service (QoS)TTL configuration(Extend/Spoof)Band SelectionMobile Frequency BandEurope/Middle East/Africa/Asia Pacific/Brazil
EU version(EG18-EA Inside)
LTE-FDD:B1/B3/B5/B7/B8/B20/B28LTE-TDD: B38/B40/B41WCDMA: B1/B3/B5/B8North America
US version(EG18-NA Inside)
LTE-FDD: B2/B4/B5/B7/B12/B13/B14/B17/B25/B26/B29/B30/B66/B71LTE-TDD: B41WCDMA: B2/B4/B5PhysicalProduct Dimension: 253x152.5x48.2mm (LxWxH)Package Dimension: 415x265x90mm (LxWxH)PowerAC Power Adapter: Input: 90~260V Output: 12V, 1.5ADC input (12V-1.5A) Barrel PlugSMSSend MessageReceive MessageEnvironmentalOperation Temperature: 0° C to +45° CStorage Temperature: -40° C to +70° CRelative Humidity: 5% to 95% Non-CondPackage Contents4G LTE WiFi RouterPower AdapterRJ45 Ethernet CableQuick Installation GuideSystem RequirementsMicrosoft Windows 98SE/NT/2000/XP/Vista™/7/8/8.1/10, MAC OS, NetWare, UNIX or Linux, Firefox 12.0, Chrome 20.0, Safari 4.0, or other Java-enabled browser Subscription with an internet service provider (for internet access)
