ModelWR300HardwareProcessor580 MHz CPUFlash8 MB (64 Mbit) NORDDR64 MB (512 Mbit) DDRAntenna2× Fixed Wi-Fi AntennasInterfaces1× 10/100 Mbps WAN Port3× 10/100 Mbps LAN PortsButtonsWPS Button, Reset Button Power Supply
5 V / 1 A
Dimensions (W×D×H)118×80×27.5 mm
4.65×3.15×1.08 inches
WirelessWireless StandardsIEEE 802.11n/g/b Frequency2.4 GHzSignal Rate300 Mbps (2.4 GHz)Transmit PowerCE: <20 dBm (2.4 GHz)FCC: <30 dBm (2.4 GHz)Wireless SecurityWPA-PSK, WPA2-PSK, WPA-PSK/WPA2-PSKSoftware
WAN TypeDynamic IP/Static IP/PPPoEManagementParental Control (Domain/IP/MAC Filter)Device Management PanelGuest NetworkDHCPServer, DHCP Client List, Address ReservationDynamic DNSCompatible with 15 more DDNS providersGuest Network2.4 GHz Guest Network × 1NATPort Forwarding, Port Triggering, UPnP, DMZVPNProtocols: Wireguard/L2TP/PPTPPerformance (TBD):
43 Mbps Uplink / 49 Mbps Downlink (Wireguard Client)
FirewallSPI, DoS, PingFast Roaming Cudy Mesh Satellite (Pair with a Main Cudy Mesh Router)IP ProtocolsIPv4 / IPv6OthersPackage ContentWi-Fi RouterPower AdapterRJ45 Ethernet CableQuick Installation GuideEnvironmental RequirementsOperating Temperature: 0 ℃ ~ 40 ℃ (32 ℉ ~104 ℉)Storage Temperature: -40 ℃ ~ 70 ℃ (-40 ℉ ~ 158 ℉)
Operating Humidity: 10% ~ 90% non-condensing
Storage Humidity: 5% ~ 90% non-condensingSystem Requirements
Windows, macOS, Android, iOS, or other OS with networking capability
Firefox, Chrome, Safari, Edge, or other up-to-date web browsers
Cable/DSL/ONT modem/Internet Walloutlet/Wi-Fi or other internet source
