Modulations BPSK, QPSK, CCK, 16-QAM, 64-QAM
Receiver
Sensitivity 135M:-70dBm@10% PER
108M:-70dBm@10% PER
54M:-74dBm@10% PER
11M:-85dBm@8% PER
6M:-90dBm@10% PER
1M:-95dBm@8% PER
Transmission Rate 150Mbps(MAX)
Spread Spectrum Technology DSSS (Direct Sequence Spread Spectrum), OFDM
Wireless Transmitting Power 17dbm (MAX)
Transmission Range Indoors 100 metres, outdoors 300 metres
(according to the actual situation)
Operating Environment Operating Temperature: 0°C to 40°C (32°F to 104°F)
Storage Temperature: -40°C to 70°C (-40°F to 158°F)
Operating Humidity: 10% to 90% RH, Non-condensing
Storage Humidity: 5% to 90% RH, Non-condensing
